A metal guardrail is anchored to the face of a concrete parapet wall with a design-build configuration, finished with paint P-1. A continuous metal parapet cap protects the top of the wall. Sealant is applied all around the mounting plate intersection. The guardrail stands a minimum of 42 inches tall from the top of the parapet.
6" MIN 10" 1 1/2" 1" 1" 1' - 0" SEALANT ALL AROUND GUARDRAIL (MIN 42" TALL FROM T/PARAPET), BY DESIGN BUILD, PAINT P-1 METAL PARAPET CAP 1/4 1/2" = 1'-0" A5.12 13 ROOF DRAIN PLAN
