A hollow metal door frame profile is installed within a gypsum board partition assembly per the schedule. Minimum two one-inch long steel screws secure each anchor in accordance with NFPA 80. Gypsum wallboard maintains a minimum one-half inch penetration past the frame profile. Maximum clearances of one-eighth inch at the jamb and three-quarters inch at the sill are maintained per NFPA 80.
MIN TWO 1" LONG STEEL SCREWS PER ANCHOR, PER NFPA 80 A. JAMB (HEAD SIM) B. SILL SEE SHEET A-601.1 FOR TYPICAL FRAMING DETAILS AT OPENINGS FRAME PROFILE AS SCHEDULED DOOR AS SCHEDULED 1/8" 3/4" MIN 1/2" WALLBOARD PENETRATION PER NFPA 80 MAX 1/8" CLEARANCE PER NFPA 80 MAX 3/4" CLEARANCE PER NFPA 80
