A metal stud bulkhead assembly ties into a structural wall with metal C-H studs and channel studs. The cavity is filled with fiberglass sound batt insulation. The assembly is enclosed with one-inch Type X gypsum board shaft liner and two layers of five-eighths-inch Type X gypsum board on the ceiling finish.
FIBERGLASS SOUND BATT 1" TYPE 'X' GYPSUM BOARD SHAFT LINER METAL C-H STUDS (2) LAYERS 5/8" TYPE 'X' GYP. BOARD CEILING FINISH (REF. RPC AND SCHEDULES) CHANNEL STUDS 3C12 A1 2GYP.
