A safety tieback is mounted adjacent to mechanical equipment on a premanufactured insulated equipment curb. The insulated curb bears on an eight-inch concrete leveling curb, which sits atop a concrete deck poured over a metal deck. Continuous one-and-a-half-inch neoprene cushioning separates components at the top of the curb assembly. Reglet and counterflashing protect the vertical transition along the curb face.
PREMANUFACTURED INSULATED EQUIPMENT CURB REGLET AND COUNTERFLASHING CONT 1 1/2" NEOPRENE CUSHION MECHANICAL EQUIPMENT 10" MIN 1' - 0" MIN 8" CONCRETE LEVELING CURB CONCRETE DECK METAL DECK 4" MIN 3" 1 1/2" = 1'-0" 02 SAFETY TIEBACK
