A precast concrete wall corner joint incorporates a joint backing and elastomeric sealant over a ceramic insulation blanket. The joint accommodates thermal movement and fire rating requirements, with specific recess depths indicated for one through four-hour fire-rated assemblies. Standard three-quarter-inch chamfers are detailed at the concrete edges, along with notes for alternate conditions at butt ends.
