An inside corner assembly of an aluminum curtain wall system featuring intersecting aluminum curtain wall mullions fitted with exterior aluminum vertical fins and horizontal fins. Glazing units engage the framing members with specific dimensional clearances, including four-inch mullion depths and various offset dimensions down to one and three-eighths inches. The framing geometry accommodates the internal corner junction with coordinated sightlines and variable profile dimensions.
GLAZING UNIT ALUM HORIZONTAL FIN ALUM CURTAIN WALL MULLION ALUM VERTICAL FIN ALUM HORIZONTAL FIN 4" 4" 4 1/2" 4 1/2" 6 1/2" 1 1/4" 1 3/4" 1 3/4" 3 3/8" 3 3/8" 1 3/8" 6 1/2" 4" 4" 1' - 4" 1' - 4" 4" 4" VARIES VARIES
