A one-and-a-half-inch diameter pipe handrail connects to the wall using a three-inch diameter by one-quarter-inch thick plate bracket. The handrail ends return to the wall typically, maintaining a minimum one-and-a-half-inch clearance from the wall surface. Brackets are spaced at a maximum of five feet on center for all wall-mounted handrails. The assembly fastens to a scheduled partition with required blocking provided behind the finish material to resist a design load of fifty pounds per foot applied in any direction.
1 1/2" 1 1/4" 1 1/2" 1 1/2" 1/4" 1 1/2" PIPE HANDRAIL RETURN HANDRAIL ENDS TO WALL TYP. 3" DIA. X 1/4" PLATE BRACKET NOTE: - PROVIDE BRACKETS @ 5'-0" MAX O.C. AT ALL WALL MOUNTED HANDRAILS. - HANDRAIL TO BE DESIGNED TO RESIST A LOAD OF 50 PLF APPLIED IN ANY DIRECTION AT THE TOP AND TO TRANSFER THIS LOAD THROUGH THE SUPPORTS TO THE STRUCTURE PARTITION AS SCHED. PROVIDE BLOCKING AS REQ. MIN. 1 1/2"
