A scheduled door and frame assembly aligns with a solid surface transition piece sitting on the centerline of the door. The tile finish rests on a mortar bed and a crack suppression membrane over grout, with shims used as required for alignment. The carpet finish is set on the opposite side with shims for alignment per the finish schedule.
CARPET, SEE FINISH SCHEULE. SHIM AS REQUIRED FOR ALIGNMENT GROUT CRACK SUPPRESSION MEMBRANE MORTAR BED SCHEDULED TILE ALIGN SOLID SURFACE TRANSITION ALIGN SCHEDULED DOOR AND FRAME ASSEMBLY OF DOOR
