The assembly consists of 2-7/8-inch steel posts spaced at 8 feet on center supporting a 1-5/8-inch outside diameter top rail and brace rail. Chain link fabric features 9 gauge wire with 2-inch square mesh, reinforced with diagonal truss rods across panel bays. Posts extend down into concrete footings measuring 12 inches in diameter and 36 inches deep or sized as required. A separate footing detail indicates a 4-inch or 2-7/8-inch diameter post embedded into a concrete footing with 3 inches of minimum cover and 4 inches of clearance beneath the post end. General notes specify that the chain link fence and gate contractor must design and detail all members and connections for required wind velocity, all calculations must be performed by a registered structural engineer in the state of Nevada, and all joints must be welded and ground smooth.
