A pre-formed drainage channel is embedded within the sidewalk concrete slab, featuring a narrow 0.47-inch slot opening at the surface designed to align with joints in the paving. The overall channel depth varies to accommodate drainage requirements. The concrete slab encases the upper portion of the drain body, maintaining flush transitions with the surrounding hardscape.
0.47" SLOT OPENING, ALIGN WITH JOINTIN IN PAVING -1' - 1 1/2" OVERALL CHANNEL DEPTH VARIES 5 1/8" 3 1/4" 3/4" -2' - 5 1/2" SIDEWALK CONCRETE SLAB; SCD
