A plastic bumper guard and crash rail mount over a wall protection sheet finished with a J-trim edge. The assembly is installed at a height of three feet above the finished floor to protect wall surfaces from impact damage.
3' - 0" WP-4 10 26 00 CRASH RAIL 10 26 00 PLASTIC BUMPER GUARD 10 26 00 WALL PROTECTION SHEET WITH J-TRIM A9.03 19 A9.03 24
