A WT5x15 structural tee connects to a structural column with a one-inch typical clearance, secured by typical quarter-inch fillet welds. A four-inch by three-inch by quarter-inch steel plate featuring a five-eighth-inch center hole projects toward the screen centerline. Connection elements for the screen are provided by the manufacturer per the architectural drawings.
PLAN - 03 42' - 0 3/8" 4"x3"x1/4" PLATE W/ 5/8" HOLE AT CENTER 1/4 TYP 1/4 CONNECTION ELEMENTS BY SCREEN MANUFACTURE, SEE ARCH DWGS 1" TYP 10" CL OF SCREEN WT5x15 TYP TYP 1/4 COLUMN
