An existing structural steel column is boxed out with one and five-eighths inch twenty-five gauge steel studs sized per structural drawings. One layer of Sheetrock Firecode C core panels is attached to frame the enclosure per UL design X528. One-and-one-quarter-inch leg corner beads are secured to the wallboard using number six by one-inch screws. The complete assembly achieves a one-hour fire rating in accordance with UL design X528.
EXISTING COLUMN 1- 5/8" 25 GAUGE STL STUDS (SEE STRUCTURAL) 1 LAYER SHEETROCK FIRECODE C CORE PANELS (UL DEX X528) 1-1/4" LEG CORNER BEAD FASTEND TO WALLBOARD WITH NO. 6X1" SCREWS NOTE: ASSEMBLY HAS 1 HOUR FIRE RATING PER UL DESIGN X528
