The roof membrane is fully adhered to the back face of the wall panel. A termination bar is fastened to the wall at 12 inches on center and is continuously sealed at the top edge. A surface-mounted reglet is installed above the termination bar, with sealant applied at the joint. Exterior elastomeric coating is applied to the wall surface. Extra sealant is required at panel joints and chamfered panel ends.
Text on the drawing
TERMINATION BAR FASTENED TO WALL AT 12" O.C. AND CONTINUOUSLY SEALED AT TOP EDGE ROOF MEMBRANE FULLY ADHERED TO BACK FACE OF WALL PANEL EXTRA SEALANT TO BE USED AT PANEL JOINTS AND CHAMFERED PANEL ENDS AS REQUIRED SEALANT SURFACE MOUNTED REGLET EXTERIOR ELASTOMERIC COATING A-60000 | 6" = 1'-0" RECESSED KEY BOX MOUNTING DETAIL 8
