An HSS 3x3 structural steel column supports the walkway framing assembly, anchored with stainless steel bent plates per structural specifications. Insulated metal wall panels enclose the assembly, incorporating a minimum of 3 inches of batt insulation. Stainless steel weld studs with cap nuts secure the exterior trim and finish elements. Fasteners and walkway bolting frames are coordinated with structural framing requirements.
6 1/2" 5" 5" 1'-2" RE: IMP OUTSIDE CORNER DETAIL IMP WALL PANEL WALKWAY BOLTING FRAME, SST, PER STRUC WELD STUD W/ SST CAP NUT 3 1/2" C L C L 10 3.A-501 BENT PLATE, SST, PER STRUC BATT INSUL, MIN 3" HSS3X3 COLUMN PER STRUCTURAL
