Rough opening layout dimensions require a minimum eleven-inch clearance from adjacent wall conditions. This framing or opening configuration applies similarly to door openings per the architectural plans.
MIN 11" MIN 11" 1 2 WINDOW OPENING PER PLANS (SIM. @ DOOR)
