A hollow metal door frame sits within a gypsum-clad partition with lateral bracing and a continuous steel runner. Blackened steel wall cladding aligns with the door frame assembly, avoiding direct anchoring into the door and frame. Partition type varies with conditions.
SEE PARTITION TYPE FOR VARYING CONDITIONS 1 15/16" PARTITION TYPE VARIES WITH 09 2216 LATERAL BRACING 09 2216 CONTINUOUS STEEL RUNNER 1 1/8" 1 1/2" 1 5/8" 08 1113 HM DOOR AND FRAME BLACKENED STEEL CLADDING OVER RATED METAL FRAME DOOR. AVOID ANCHORING DIRECTLY INTO DOOR & FRAME BLACKENED STEEL WALL CLADDING ALIGN
