A cold-formed metal stud partition frames a typical door head and jamb assembly. A hollow metal frame wraps the wall opening, featuring a frame overlap of one-half inch over gypsum board at rated doors. Box beam headers and jambs reinforce the rough opening as required by the partition layout.
PARTITION AS OCCURS - SEE PLANS BOX BEAM AT JAMB TYP HOLLOW METAL FRAME BOX BEAM AT JAMB TYP WALL AS OCCURS FRAME OVERLAPS GYPSUM 1/2" AT RATED DOORS, TYP. 4"
