Architectural · A-TDBK7

In-Swinging Door With Forward Approach

Units: imperial
Sheet: A9.50
Discipline: Architectural

Elements

Doors Entrances Floors / Slabs Walls

Text on the drawing

5' - 0" MIN 7' - 2" MIN 6'-4" MIN 4' - 6" 1' - 6" 3' - 0"
