An all-glass partition head connects to a suspended gypsum board ceiling assembly using a one-and-three-quarter-inch glazing rail. Shims and attachment hardware secure the glazing channel to the overhead structural framing as required. The suspended ceiling framing is hung using wire hangers tied back to the structure above.
08 8000 1 3/4" GLAZING RAIL GYP BD CEILING SUSPENDED FRAMING PER 0' - 2" FRAMING 08 42 20 SHIM & ATTACHMENT TO FRAMING AS REQ'D 3" = 1'-0" 7 ALL-GLASS TYP JOINT, & CORNER
