This plan detail shows a steel guardrail and handrail assembly at a stair landing with vertical guardrail posts positioned relative to the riser line and the front edge of the tread below. A four and a half inch flat plate is welded on top of a bent closure plate to provide support for the balusters. The spacing between balusters, and between guardrails and balusters, is maintained at a maximum of four inches on center. Bottom rails of guardrails and the top guardrail pipe align with the landing geometry.
1 1/2" WIDTH AS INDICATED ON PLANS 1 1/2" HANDRAIL VERTICAL GUARDRAIL POSTS SPACE BETWEEN BALUSTERS, AND GUARDRAILS AND BALUSTERS, SHALL BE 4" OC MAX FRONT EDGE OF TREAD BELOW LINE OF RISER FRONT EDGE OF TREAD BELOW BENT CLOSURE PLATE BOTTOM RAILS OF GUARDRAILS 4 1/2" FLAT PLATE WELDED ON TOP OF BENT CLOSURE PLATE FOR BALUSTER SUPPORT - REF SECTION 04 LINE OF TOP GUARDRAIL PIPE A8.11/11
