The assembly is built upon a reinforced concrete substrate with crushed stone or tile at the drain incorporating weep holes. A waterproof membrane with a sloped fill creates positive drainage toward the central drain, which is set flush with the finished tile floor. The floor finish consists of ceramic tile installed over thinset mortar, a tile backer board, and the underlying waterproof membrane. At the perimeter and threshold, a mortar bed supports ceramic tile and bullnose edge tile with a maximum half-inch height transition.
BULLNOSE TILE MORTAR BED 5" 2'-6", N.T.S. REINFORCING CRUSHED TILE OR STONE WITH WEEP HOLES AT DRAIN SET DRAIN FLUSH WITH TILE FLUSH . CERAMIC TILE O/ THINSET MORTAR O/ TILE BACKER BOARD O/ WP MEMBRANE 6", MIN. MAX. 1/2" CERAMIC TILE WATERPROOF MEMBRANE WITH SLOPED FILL BELOW SLOPE TO DRAIN 2" 6"
