The window wall sill sits above an interior floor slab adjacent to an exterior amenity deck with a minimum two percent slope. A structural anchoring assembly secures the window framing to the concrete substrate. The exterior deck assembly requires coordination with structural drawings.
INTERIOR AMENITY DECK SLOPE 2% MIN FOG BOM 0' - 6" TOSS 1 A04-9205 SEE STRUCTURAL DRAWINGS
