The supply fan rests on two-inch spring isolators supported by a concrete pad provided by the general contractor, set atop roofing materials and finished roof construction with waterproofing by others. A duct connects to the supply fan through an ultraviolet-resistant flexible connection built inside out and a backdraft damper. The duct layout requires no vertical offset with a minimum of two point five diameters clearance. The supply fan unit is labeled SF A-1.
CL UV RESISTANT FLEX CONNECTION BUILT INSIDE OUT WATERPROOFING BY OTHERS ROOFING MATERIALS AS REQUIRED BY GENERAL CONTRACTOR 2" SPRING ISOLATORS CONCRETE PAD BY G.C, AS SHOWN ON PLANS BACKDRAFT DAMPER NO VERT. OFFSET (MIN. 2.5 DIAMETERS) FINISHED ROOF DUCT SF A-1
