This millwork section shows a break room island cabinet with a pull-out trash receptacle assembly. The countertop is scheduled per plans and features a one-foot overhang supported by the cabinet structure. The cabinet base is elevated four inches above the finished floor, with a three-inch toe kick setback. The pull-out mechanism is integrated within the cabinet carcass, which is constructed of wood framing and panels.
Text on the drawing
SCHEDULED COUNTERTOP RE: PLANS REFER TO ELEVATION 1' - 0" 3" 4"
Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
