An aluminum curtain wall system mullion rests on shims atop the building structure, retaining an insulated glass unit above. A backer rod and sealant joint seals the interface between the sill framing and the substrate below. Below the sill, pre-finished aluminum composite metal panels attach over weather-resistive barriers and glass-mat gypsum sheathing. Cold-formed metal stud framing supports the exterior wall assembly, filled with insulation as required by energy calculations.
SHIM, AS REQUIRED INSULATED GLASS ALUMINUM CURTAIN WALL SYSTEM MULLION BACKER ROD AND SEALANT METAL STUD FRAMING INSULATION PER ENERGY CALCULATIONS PRE-FINISHED ALUMINUM COMPOSITE METAL PANEL WRB OVER GLASS-MAT GYPSUM SHEATHING BOARD
