A one-and-a-half-inch diameter stainless steel handrail is supported by a stainless steel bracket with a two-inch cap positioned three feet zero inches above the nosing. The assembly features a nine-sixteenth-inch laminated and tempered glass panel anchored to a painted hollow structural section stringer per structural requirements. The handrail sits one and one-half inches clear of the bracket connection, and the glass guardrail extends three feet six inches total height above the nosing.
1 1/2" DIA. STAINLESS STEEL HANDRAIL HSS STRINGER, PAINTED, RE: STRUCTURAL 9/16" LAMINATED, TEMPERED GLASS PANEL, SEE SPECS. STAINLESS STEEL HANDRAIL BRACKET W/ 2" CAP AT NOSING 3'-6" 1 1/2" 3 1/2" AT NOSING 3'-0" 1" 6" 4
