A prefinished sheet metal splash pan connects to the downspout via fastening tabs and bends as required to match the slope of the roof. The pan measures one foot in length, sloping from an eight-inch width down to a six-inch width at the discharge end. The tab fastens to the downspout while the bottom of the pan aligns with the roof pitch.
PREFINISHED SHEET METAL SPLASH PAN 1'-0" 2" 4" 1" 8" 6" 3" SLOPE PLAN VIEW SECTION VIEW FASTEN TAB TO DOWNSPOUT - BEND TAB AS REQUIRED TO ALLOW BOTTOM OF PAN TO MATCH SLOPE OF ROOF
