A custom perforated stair panel features graded opening sizes ranging from 0.25 inches to 2 inches. Dimensions detail spacing configurations including eight equally spaced openings at 2.75 inches spanning 1 foot 7.25 inches, and eighteen equally spaced openings at 3 inches spanning 4 feet 5 inches. Material is specified as A572 Grade D2 steel plate.
4 " 8 E Q U A L L Y S P A C E D @ 2 . 7 5 " 1 ' - 7 1 / 4 " 3 " 8 " 7 E Q U A L L Y S P A C E D @ 2 . 7 5 " 1 ' - 7 1 / 4 " 3 " 2 " X 2 " 1 8 E Q U A L L Y S P A C E D @ 3 " 4 ' - 5 " 2 ' - 5 " 1.75" x 1.75" OPENING 1.5" x 1.5" OPENING 1.25" x 1.25" OPENING 1" x 1" OPENING .75" x .75" OPENING .5" x .5" OPENING .25" x .25" OPENING 2" x 2" OPENING 2" x 2" OPENING A572 D2
