Suspended ceiling framing details illustrate wall molding installation requirements with hanger wire spacing limitations. The ceiling grid tee connects to perimeter wall molding with specified maximum distance of 8 inches and minimum distance of 2 inches. Hanger wire placement from the wall is restricted to a maximum of 3 inches.
3" (76mm) MAX. figure 1 figure 4a Attached Wall Molding Requirements Wall MAX. 8" (202mm) MIN. 2" (50 mm) figure 4b Unattached Wall Molding Requirements
