Gypsum board partitions terminate at a sliding curtain door mullion framing assembly. Metal corner beads finish the gypsum board edges adjacent to the mullion. The partition is constructed with scheduled metal studs and gypsum board, keyed to the reflected ceiling plan.
GYP BD-1 SEE RCP GYP BD-1 SEE RCP SCHEDULED PARTITION SLIDING CURTAIN DOOR METAL CORNER BEAD
