Text on the drawing
1ST FL. 424.65' DOORS PER SCHEDULE DOORS PER SCHEDULE A8 1' - 4" 6' - 2" 6' - 2" 2' - 8" 17' - 4 3/4" 1' - 8" 9' - 9" 7 A7.51 Sim 4 A7.51 Sim 17 A7.51 7 A7.01 Sim @ EXTERIOR
Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
