A 2x4 aluminum field-mold frame with an integrated door stop supports the head condition of a field-molded door positioned below. Field-mold glazing is installed directly into the frame assembly according to manufacturer specifications. The door unit is installed per plan requirements and manufacturer guidelines.
INSTALL STOREFRONT GLAZING PER MFG. SPEC EXTERIOR INTERIOR 2x4 ALUMINUM STOREFRONT FRAME W/ DOOR STOP STOREFRONT DOOR PER PLAN. INSTALL PER MFG SPEC INSTALL FIELD MOLD GLAZING PER MFG. SPEC 2x4 ALUMINUM FIELD MOLD FRAME W/ DOOR STOP FIELD MOLD DOOR PER PLAN. INSTALL PER MFG SPEC
