A structural steel column bears on a base plate secured to an embed plate within a concrete dry dock floor. The assembly uses eight bolt stacks per base plate, each consisting of a one-and-a-half-inch diameter ASTM A325 bolt measuring six and a half inches long, two ASTM F436 washers, an ASTM F959 Type 325 direct tension indicator washer, and a one-and-a-half-inch thick plate washer. The embed plate and dry dock floor are marked as not part of this contract, and all bolt stacks are shipped separately.
EMBED PLATE, NOT PART OF THIS CONTRACT TYPICAL BASE PLATE BOLT STACK 1 1/2" DIA ASTM A325 BOLT X 6 1/2" 1 1/2" DIA ASTM F436 WASHER 1 1/2" DIA ASTM F959 TYPE 325 DTI WASHER 1 1/2" DIA ASTM F436 WASHER 1 1/2" THICK PLATE WASHER PER 7/3.S-503 PROVIDE 8 BOLT STACKS PER BASE PLATE SHIP BOLT STACKS SEPARATE BASE PLATE DRY DOCK FLOOR, NOT PART OF THIS CONTRACT COLUMN PER PLAN
