A-SZYE7 — Pipe Protection Detail

Architectural · A-SZYE7

Pipe Protection Detail

Units: metric
Sheet: A504
Discipline: Architectural

Materials

Elements

Anchors / Embeds Floors / Slabs

Connections

Base Plate / Anchorage Bolted Connection

Text on the drawing

PLUMBING PIPE STEEL PIPE PROTECTION COVER STEEL FLANGE BOLTED TO THE CONC. SLAB PAINT ASSEMBLY SAFETY YELLOW FOR LOCATIONS AND HEIGHTS, SEE ELECTRICAL SHEETS E503-1 AND E503-2 1.5 STEEL PIPE PROTECTION COVER CLEANOUT PLUMBING PIPE STEEL FLANGE BOLTED TO CONC SLAB 1.5
