Architectural · A-SY5VC

Area of Refuge Signage Braille Positioning Detail

About this detail

Area of refuge signage detail with a magnified callout circle showing braille positioning requirements. Minimum three-eighths inch spacing is maintained above and below the raised text and braille dots per ICC A117.1 Figure 703.4.4.

AREA OF REFUGE 3/8" MIN. 3/8" MIN. ICC A117.1 FIGURE 703.4.4 POSITION OF BRAILLE

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
