The head condition for a folding panel door aligns with framing and exterior wall construction. The folding panel door per schedule sits below structural steel elements and custom track supports. Fasteners and anchors secure the framing components to the structural backup. Flashing and weatherproofing layers integrate the door head with the adjacent wall assembly.
FOLDING PANEL DOOR PER SCHEDULE W53 WP F.O. FRAMING SEE FOR SIMILAR CANOPY DETAIL NOTES / 4 A8.41
