The twenty-four-inch diameter concrete pole base is positioned relative to the parking stall stripe and curb conditions. The light pole is coordinated per electrical requirements, with the base centered directly on the parking stripe. The layout coordinates the face of the curb and the line of the car overhang to ensure proper clearance.
CENTER BASE ON PARKING STRIPE 24" DIA. CONC. POLE BASE LIGHT POLE PER ELEC. LINE OF CAR OVERHANG FACE OF CURB PARKING STALL STRIPE CL OF STALL STRIPE PLAN AT CURB CONDITION PLAN AT PARKING STRIPE CONDITION
