A-SXCCF — Stair Guardrail Section

Architectural · A-SXCCF

Stair Guardrail Section

Scale: SCALE: 1" = 1'-0"
Units: imperial
Sheet: A503
Discipline: Architectural

Materials

Metal (misc.)Steel

Elements

Columns Railings / Guards Stairs

Text on the drawing

2' - 10" 3' - 6" 2 1/4" 1 1/4"Ø STD PIPE GUARD RAIL 1 1/4"Ø STD PIPE HANDRAIL 1/2"Ø BAR PICKETS @ 4" OC 1 1/4"Ø STD PIPE PIPE POST 1 1/4"Ø STD PIPE PIPE RAIL STAIR STRINGER STAIR TREAD TREAD NOSE 1/2"Ø BAR @ EACH POST 2 7/16" 3 1/8" A503
