The assembly features a one and a half inch diameter painted steel handrail mounted at a height of three feet six inches above the finished base. Painted steel posts of one and a half inch diameter are spaced at four feet on center. Vertical one-half-inch diameter painted round bar stock infill is spaced at four inches on center typical. The base attachment is detailed separately on structural details one and seven of sheet SD-7.
3' - 6" . 1 1/2" DIAM. PAINTED STEEL HANDRAIL 1 1/2" DIAM. PAINTED STEEL POST AT 4' O.C. SEE ELEVATIONS BASE ATTACHMENT, SEE STRUCTURAL DETAILS 1/SD-7, 7/SD-7 1/2" DIAM. PAINTED ROUND BAR STOCK, VERTICAL,TYP. AT 4" O.C. SEE ELEVATIONS
