Plate metal guardrail designated as DMP-2 features fold lines and one-half inch reveals along its profile. The guardrail stands at a height of five feet relative to the floor opening. A built-up slab matches the stair landing elevation at the base of the assembly.
MATCH LINE DMP-2 PLATE METAL GUARDRAIL FOLD LINE 1/2" REVEAL 1/2" REVEAL 5 ' - 0 " O P E N B U I L T U P S L A B T O M A T C H S T A I R L A N D I N G E L E V A T I O N
