This drawing outlines the precise geometric layout and spacing dimensions for a custom stair perforation pattern rotated at an angle of 26.36 degrees. Horizontal and vertical dimensions range from 1/4 inch to 4 inches, establishing exact centerlines and offsets for the repeating parallelogram perforations.
3 " 3 " 2 3 / 4 " 2 3 / 4 " 2 3 / 4 " 2 3 / 4 " 2 3 / 4 " 2 3 / 4 " 2 3 / 4 " 4 " 2 " 2 " 2 " 1 / 4 " 2 1 / 2 " 1 / 2 " 2 1 / 4 " 3 / 4 " 2 " 1 " 1 3 / 4 " 1 1 / 4 " 1 1 / 2 " 1 1 / 2 " 1 1 / 4 " 1 3 / 4 " 1 " 2 " 1 " 2 " 1 " 2 " 1 / 2 " 3 1 / 2 " 3 / 4 " 3 1 / 4 " 1 " 3 " 1 1 / 4 " 2 3 / 4 " 1 1 / 2 " 2 1 / 2 " 1 3 / 4 " 2 1 / 4 " 2 6 . 3 6 ° *PATTERN HAS BEEN ROTATED FOR CLARITY
