A-SSMNR — Stair at Slab, Typ

Architectural · A-SSMNR

Stair at Slab, Typ

Scale: 1 1/2" = 1'-0"
Units: imperial
Sheet: A5.03
Discipline: Architectural

Materials

Concrete Metal (misc.)Steel

Elements

Connections / Plates Floors / Slabs Stairs

Connections

Bolted Connection Welded Connection

Text on the drawing

BASEMENT T.O.S. 413' - 7 3/4" 1 1/2" 7" MAX 1/4" / 1'-0" POURED CONCRETE TREAD SHEET METAL BENT PLATE RISER AND PAN. SEE STRUC. STEEL PLATE STRINGER. SEE STRUC. F1 BOTTOM OF STRINGER BOLTED TO SLAB WITH TAB WELDED TO INTERIOR OF STRINGER PLATE

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
