A structural steel bent plate guard protects exterior downspouts mounted against a painted concrete tilt wall. The three-eighths-inch thick by four-foot high steel guard is coated with two coats of gloss enamel matching the building color and positioned with its bottom edge two inches above the downspout opening. Each side attaches to the concrete wall using three half-inch diameter wedge anchors spaced at twenty inches on center with a maximum of four inches from the top and bottom. The contractor must verify the downspout size prior to fabricating the steel guards.
NOTES: 1. PROVIDE STEEL PROTECTION AT DOWNSPOUTS ONLY WHERE LOCATED SUCH THAT THEY ARE NOT PROTECTED BY STAIR WALLS OR CURBS / PLANTERS. PAINTED CONCRETE TILT WALL DOWNSPOUT - CONTRACTOR TO VERIFY SIZE OF DOWNSPOUT (MAY VARY) PRIOR TO FABRICATION OF STEEL GUARDS. 4' HIGH X 3/8" THK. STRUCTURAL STEEL BENT PLATE GUARD TO + 4'-0" PAINTED (2) COATS GLOSS ENAMEL TO MATCH BUILDING. MOUNT BOTTOM OF STEEL GUARD AT 2" ABOVE THE DOWNSPOUT OPENING. ATTACH EA. SIDE WITH THREE 1/2" DIA. WEDGE ANCHORS AT 20" O.C. AND 4" MAX. FROM TOP & BOT.
