A hollow metal frame connects to a partition assembly featuring a continuous steel runner and lateral bracing. Dimensions indicate a one-half-inch offset, one-inch clearance, two-inch frame depth, and five-eighths-inch reveal. Varying partition types dictate specific conditions as noted.
1 15/16" 1 9/16" VARIES 1/2" PARTITION TYPE VARIES WITH 2" 5/8" SEE PARTITION TYPE FOR VARYING CONDITIONS 09 2216 LATERAL BRACING 09 2216 CONTINUOUS STEEL RUNNER 08 1113 HM FRAME 1"
