This roof drain assembly features a stainless steel gutter pan supported by steel support angles and gypsum sheathing at the eave. A TPO gutter liner laps over the adjacent roofing membrane to maintain a watertight seal around the drainage system. A gutter ridge is visible beyond the central drain opening, which is spaced five inches from the centerline on either side.
5" 5" TPO gutter liner, lap over roofing membrane SS gutter pan Steel support angle Gyp sheathing Gutter ridge beyond
