This casework assembly features a total depth of one foot eight inches. The upper section includes adjustable melamine shelves, typical, with quantities determined by interior elevations. The middle section contains adjustable hardboard dividers creating twenty-one bays in total, with plastic laminate applied to all exposed faces and edges. The lower cabinet section includes adjustable melamine shelving and a six-inch base as scheduled. Cabinet finishes and hardware pulls are provided per project specifications.
