A stainless steel Schluter Vinpro-U transition profile anchors directly to the concrete slab between a resinous flooring finish and a carpet tile or walkoff mat. The transition strip is sealed to the concrete substrate for water resistance. The adjacent carpet tile and resinous flooring are installed flush with the profile flanges.
CARPET TILE/WALKOFF MAT, REFER TO FINISH PLAN RESINOUS FLOORING S.S. SCHLUTER VINPRO-U TRANSITION ANCHOR TO SLAB AND SEAL TO CONCRETE FOR WATER RESISTANCE CARPET TILE/WALKOFF MAT, REFER TO FINISH PLAN RESINOUS FLOORING S.S. SCHLUTER VINPRO-U TRANSITION ANCHOR TO SLAB AND SEAL TO CONCRETE FOR WATER RESISTANCE
