This interior architectural section details a transition between a suspended two-by-two acoustical ceiling grid and a gypsum board-clad soffit featuring tongue-and-groove walnut paneling. The lower ceiling consists of a standard acoustical tile system suspended by wire hangers and terminating at the soffit edge with typical metal trim edges. The dropped vertical soffit features a taped and finished gypsum face painted with finish P-11, returning upward to meet an upper ceiling level. At the upper ceiling boundary, tongue-and-groove walnut panels are detailed with a quarter-inch reveal against painted plywood finished with coating P-7.
T&G WALNUT METAL EDGES (TYP) TAPE & FINISH 2x2 ACOUSTICAL CEILING GRID SEE RCP GYP FACE FINISHED WITH P-11 1/4" REVEAL - PAINT PLYWOOD P-7
