This isometric and sectional detail shows a roof cricket assembly built over a structural steel deck and wood roof truss framing. The assembly is surfaced with TPO single-ply roofing and reinforced membrane over sloped rigid insulation. A continuous metal cleat is fastened at 16 inches on center along the edge. Sealant and fasteners secure the single-ply roofing at 24 inches on center on both sides of the cricket, transitioning to a concrete tilt-up wall panel.
SEAL TPO SINGLE PLY ROOFING FASTENED @ 24" O.C. BOTH SIDES RIGID INSULATION A A SLOPED INWARD CONTINUOUS CLEAT FASTENED @ 16" O.C. SECTION AA STEEL DECK (SEE STRUCT.) CONCRETE TILT- UP PANEL WOOD ROOF TRUSS - SEE STRUCTURAL FASTENER & FASTENER PLATE, INSTALL PER MANUFACTURER REINFORCED MEMBRANE RIGID INSULATION
